|Style||Modern / Contemporary|
|Delivery Time||2 to 3 weeks|
|Warranty||5 Year limited mechanical and finish warranty.|
|Handle Size||8-1/2in.(216mm) x 1in. (25mm)|
|Plate Size||17-1/2in. (445mm)x 2-11/16in.(68mm)|
|Rotate Direction||Only Downwards|
Use this form to contact us with questions, comments, or feedback:
Levers have a fixed stop at the top of their stroke. These lever will only rotate down, not up and down like most products found in homecenters. These European style construction yields a solid, positive feel for every lock.
Each handle has a set screw which, when tightened, eliminates "handle wobble." Set screws do not hold the handles on but serve to remove any looseness after other installation steps are completed.
These locks have heavy duty mechanisms designed to provide trouble free service. Knobs and lever handles are supported by springs mounted behind the rosettes and sideplates. These springs return the handles back to the "rest" position and prevent lever sag.
Latches are heavy duty diecast construction, with strong internal springs, solid brass nose bolts and sintered metal cams.
A plastic bushing located in the joint between handle and rosette ensures a friction free wear surface. This prevents metal from bearing on metal and provides smooth long-lasting operation.
Spindles are spring loaded "half spindles" pre-installed into the base of each handle. Half spindles are more forgiving of imperfect door preps. If the holes in a door are drilled out of alignment the spindles still have a good chance to operate the latch without binding.
The threaded tubes inside the lock are machined brass, not steel. The use of brass ensures good threads and prevents corrosion for easy installation and long life.
